Quick delivery right gasket s
JAMES GASKETS
SKU: 681-4483
James Gaskets Graphite Fire Ring Cylinder Head Gasket .045 5-Pack - Harley-Davidson Evolution
$57.95
Free shipping on orders $99+ · Best value guarantee
affirm
From $4.82/mo with Affirm.
See if you prequalify
OUT OF STOCK
Free Shipping on orders $99+
Best Value Guarantee
30-Day Returns — see policy
Authorized Dealer — sourced direct
About James Gaskets
James Gaskets has supplied American V-twin gaskets, seals and O-rings for decades and is one of the most widely stocked names for Harley-Davidson engine, primary and transmission rebuilds. When a service manual calls for a specific gasket, James almost always has an exact-fit answer.
When servicing multiple V-twin engines or preparing for future rebuilds, having a supply of quality gaskets on hand is crucial. These James Gaskets cylinder head gaskets feature a durable graphite facing with an integrated fire ring, designed for a robust seal on Harley-Davidson Evolution engines. This 5-pack offers excellent value for shops and serious DIY riders.
Why riders pick this
- Graphite facing ensures a tight seal
- Fire ring design withstands combustion pressure
- Direct replacement for stock head gaskets
- Ideal for shops and multi-bike owners
- Designed for Harley-Davidson Evolution engines
These James Gaskets cylinder head gaskets are engineered with a graphite facing and a crucial fire ring, providing an effective seal for the combustion chamber and coolant passages in your Harley-Davidson Evolution engine. The graphite material offers excellent conformability to mating surfaces, ensuring a tight seal, while the fire ring is specifically designed to withstand the high pressures and temperatures of combustion. This 5-pack ensures you have plenty of spares for ongoing maintenance or multiple top-end jobs.
Reliable Sealing for V-Twin Performance
- Graphite facing for optimal sealing properties
- Integrated fire ring for enhanced combustion seal
- Direct OEM replacement specification
- Designed for Harley-Davidson Evolution engines
- Convenient 5-pack for multiple services
Essential for Shops and Multi-Bike Owners
Whether you're a professional technician or a dedicated V-twin enthusiast with a fleet of bikes, this 5-pack of James Gaskets cylinder head gaskets is an intelligent investment. Stock up on these critical components to ensure you're always ready for a top-end refresh or unexpected repairs. Always confirm the gasket thickness and part number match your specific engine requirements before installation to ensure a proper fit and seal.
Specifications
- Brand: James Gaskets
- Manufacturer Part #: 16770-84-B
- Length: 8.35 in
- Width: 6.1 in
- Height: 1.15 in
- Weight: 0.222 lbs
Common questions
What is the thickness of this head gasket?
This gasket has a nominal thickness of 0.045 inches. It's important to confirm this thickness matches your engine's requirements for proper compression and valve clearance.
Why is a fire ring important in a head gasket?
The fire ring is a critical component that directly seals the combustion chamber, preventing hot combustion gases from escaping. It's designed to withstand extreme temperatures and pressures, contributing significantly to a reliable engine seal.
Is this a bolt-on replacement for my Harley Evolution engine?
Yes, James Gaskets manufactures these to OEM replacement specifications. However, always verify the part number and dimensions against your specific Evolution engine model and year before installation to ensure perfect compatibility.
Ordering from Vtwinbikers
- Brand new, sourced through authorized US distribution — never used, never grey-market.
- Not sure it fits? Use Shop by Bike to filter by your year and model, or email us and we will confirm before you order.
- Harley-Davidson and Indian Motorcycle is all we do, so you are talking to people who ride what you ride.
| BRAND | James Gaskets |
| TYPE | Gaskets/Seals |
| SKU | 681-4483 |
| WEIGHT | 0.22 lb |
Please contact us to confirm fitment for your specific motorcycle, or check the product title for compatibility notes.
CUSTOMER REVIEWS
4.79
24 RATINGS
5★
20
4★
3
3★
1
2★
0
1★
0
✓ VERIFIED
Oct 14, 2021
Great product! Fast delivery!
✓ VERIFIED
Sep 10, 2021
Great design! No O ring to forget and good seal on base.
✓ VERIFIED
Feb 4, 2021
Great! No leaks.
✓ VERIFIED
Jun 9, 2020
I didn't think the base gaskets would be paper. Everything else was great
✓ VERIFIED
May 12, 2020
purfect
